Operation Instruction
8
In the PTZ mode, pressing the button 1 zooms in the screen and the button 4 zooms out the screen, pressing the button
2 focuses near and button 5 focuses far, and pressing the button 3 moves to the preset and button 6 saves the preset.
Menu Button
In the Live Monitoring mode and Search mode, pressing the MENU button displays the menu icons to the right edge
of the screen.
Copy Button
Pressing the
COPY button allows you to copy video clips.
Esc Button
During menu setup, pressing the
ESC button closes the current menu or setup dialog box.
Play/Stop Button
Pressing the
PLAY/STOP button enters the playback mode, and pressing the button again exits the playback mode. When
entering the playback mode, video is paused.
When in one of the multi-view formats, pressing this button enters the Triplex mode. The DVR supports the Triplex
function: monitoring, recording and playing back at the same time.
Alarm Button
The
ALARM button has two functions. First, it will reset the DVR’s outputs including the internal buzzer during an
alarm. Second, it will display the event log when you are in the live monitoring mode unless there is an active alarm.
This operation can be user password protected.
Sequence Button
When in the live mode, pressing the SEQ button displays live channels sequentially.
PTZ Button
Pressing the PTZ button enters the PTZ (Pan/Tilt/Zoom) mode and the PTZ icon flickers. Pressing the button again
exits the PTZ mode. Pressing the arrow buttons or MENU button allows you to control properly configured cameras.
Mode Button
Pressing the
MODE button toggles between different display formats. The available formats are: PIP, 2x2, 3x2, 3x3,
4x3, 4x4 or 5x4.
Arrow Buttons
These buttons are used to navigate through menus and GUI. You can also use them to change numbers by highlighting
a number in the menu and using the Up and Down arrow buttons to increase or decrease the number’s value.
These buttons are also used to control Pan and Tilt when in the PTZ mode. When in the PIP display format, pressing
the Up and Down arrow buttons moves the position of the small screen counter-clockwise and clockwise, and pressing
the Left and Right buttons moves through screen pages.
