SpectraLink 6500 - Spectralink Media Resource Part Numbers; Spectralink IP-DECT Server 6500;Media Resource - Front

Spectralink IP-DECT Server 6500 Installation and Configuration Guide
14215700 Version 3.0
April, 2014 16
Spectralink Media Resource Types and Part Numbers
The following table includes a list of available media resources and their part numbers.
Spectralink IP-DECT Server 6500/Spectralink Media Resource Appearance and
Components
Figure 2 Add-on media resource for empty slot in a KWS 6500 Rack
The Spectralink IP-DECT Server 6500/media resource front includes the following (see figure
below).
Figure 3 Spectralink IP-DECT Server 6500/Media Resource - Front
Table 4 Spectralink Media Resource Part Numbers
Variants of Spectralink Media Resources Part Number
Spectralink Media Resource 02344400
Spectralink Media Resource mounted in 19” in Rack 02351000
Reset button
