Spectralink IP-DECT Server 6500 Installation and Configuration Guide
14215700 Version 3.0
April, 2014 24
Spectralink Base Station Appearance and Components
The base station front cover includes the following:
• LED that indicates the operating status of the unit
Figure 5 Base Station - Front view
The base station front includes the following (see figure below).
Figure 6 Base Station - Front
LED
ETH port (power
supply by PoE)
LINK/Activity
Indicator
Reset Button
