Figure 30 Synchronization Chain Layout with Alternative Sync Ways
• No. 0 is the Sync Master (can be numbered 0-255).
• It is recommended to place the Sync Master in the middle of the
building.
• Green line: Shows the primary sync ways.
• Red line: Shows the alternative sync ways.
• It is recommended to make a site planner. Every base station must
be numbered with Radio ID, Primary sync Radio ID, and
Alternative sync Radio ID.
