Digital-to-analog converter (DAC)

DocID023800 Rev 1

161/584

 __IO uint32_t DAC_TypeDef::DOR1

 DAC channel1 data output register, Address offset: 0x2C

 __IO uint32_t DAC_TypeDef::DOR2

 DAC channel2 data output register, Address offset: 0x30

 __IO uint32_t DAC_TypeDef::SR

 DAC status register, Address offset: 0x34

7.1.2 DAC_InitTypeDef

DAC_InitTypeDef is defined in the stm32f30x_dac.h

Data Fields

 uint32_t DAC_Trigger

 uint32_t DAC_WaveGeneration

 uint32_t DAC_LFSRUnmask_TriangleAmplitude

 uint32_t DAC_OutputBuffer

Field Documentation

 uint32_t DAC_InitTypeDef::DAC_Trigger

 Specifies the external trigger for the selected DAC channel. This parameter can

be a value of DAC_trigger_selection

 uint32_t DAC_InitTypeDef::DAC_WaveGeneration

 Specifies whether DAC channel noise waves or triangle waves are generated, or

whether no wave is generated. This parameter can be a value of

DAC_wave_generation

 uint32_t DAC_InitTypeDef::DAC_LFSRUnmask_TriangleAmplitude

 Specifies the LFSR mask for noise wave generation or the maximum amplitude

triangle generation for the DAC channel. This parameter can be a value of

DAC_lfsrunmask_triangleamplitude

 uint32_t DAC_InitTypeDef::DAC_OutputBuffer

 Specifies whether the DAC channel output buffer is enabled or disabled. This

parameter can be a value of DAC_output_buffer

7.2 DAC Firmware driver API description

The following section lists the various functions of the DAC library.

7.2.1 DAC Peripheral features

The device integrates two 12-bit Digital Analog Converters that can be used independently

or simultaneously (dual mode):

1. DAC channel1 with DAC_OUT1 as output

2. DAC channel2 with DAC_OUT2 as output
