SCK slave input clock as soon as CRCEN is set, and this, whatever the
value of the SPE bit.
With high bitrate frequencies, be careful when transmitting the CRC. As the
number of used CPU cycles has to be as low as possible in the CRC transfer
phase, it is forbidden to call software functions in the CRC transmission
sequence to avoid errors in the last data and CRC reception. In fact,
CRCNEXT bit has to be written before the end of the transmission/reception
of the last data.
For high bit rate frequencies, it is advised to use the DMA mode to avoid the
degradation of the SPI speed performance due to CPU accesses impacting
the SPI bandwidth.
When the STM32F30x are configured as slaves and the NSS hardware
mode is used, the NSS pin needs to be kept low between the data phase and
the CRC phase.
When the SPI is configured in slave mode with the CRC feature enabled,
CRC calculation takes place even if a high level is applied on the NSS pin.
This may happen for example in case of a multislave environment where the
communication master addresses slaves alternately.
Between a slave deselection (high level on NSS) and a new slave selection
(low level on NSS), the CRC value should be cleared on both master and
slave sides in order to resynchronize the master and slave for their
respective CRC calculation.
To clear the CRC, follow the procedure below:
1. Disable SPI using the SPI_Cmd() function.
2. Disable the CRC calculation using the SPI_CalculateCRC() function.
3. Enable the CRC calculation using the SPI_CalculateCRC() function.
4. Enable SPI using the SPI_Cmd() function.
mode or DMA mode.
