STEMME S12 User Manual

DOCUMENT NUMBER:
L500-912.820 ISSUE JUL 20, 2016
AMENDMENT: 00
DATE: 
CHAPTERPAGE 83
MAINTENANCE MANUAL STEMME S12
PLACARD LOCATION/REMARKS
The placard is illustrated in reduced scale.
Next to the ap lever of the pilot and
copilot seat.
PLACARD LOCATION/REMARKS
a) Handles:
Next to the canopy jettison knob in the
lower center part of the instrument panel.
Below the MLG-switch in the lower center
part of the instrument panel.
Canopy jettison symbol.
On the top of the canopy jettison knob.
On the head of the cowl ap operation
knob.
On the center instrument panel support
below the propeller brake and the position
handles.
On the top of the nose-cone lever.
On the top of the propeller brake handle.
On the top of the propeller position handle.
