MAINTENANCE MANUAL STEMME S12
PLACARD LOCATION/REMARKS
Below the fuel tank selector switch in the
lower center part of the instrument panel.
Next to the selector switch for the
microphone / headset.
On the top of the pilots control sticks
around the trim operation switch.
Below the MLG-switch in the lower center
part of the instrument panel.
Label for every additional switch, naming so
that the function of the switch is clearly
comprehensible by the crew.
Next to the corresponding switch.
PLACARD LOCATION/REMARKS
d) Fuses / Circuit breakers:
Next to the landing gear circuit breaker
in the lower center part of the instrument
panel.
Label for every additional fuse, naming so
that the function of the fuse is clearly com-
prehensible by the crew.
Next to the corresponding fuse.
PLACARD LOCATION/REMARKS
e) Warn and Caution Lights:
Next to the landing gear indication lights.
Next to the indication light of the auxiliary
fuel pump.
The placard is illustrated in reduced scale.
Next to the corresponding indication light.
Next to the propeller pitch control
indication light.
Next to the re warning indication light.
