STEMME S12 User Manual

DOCUMENT NUMBER:
L500-912.820 ISSUE JUL 20, 2016
AMENDMENT: 00
DATE: 
CHAPTERPAGE 318
MAINTENANCE MANUAL STEMME S12
Figure 3.4.6.a.
Diagram of the Fuel System
Feeder Tank
Drainer
Pump o - Switch Low fuel - switch
Right Fuel Tank
Fuel-Tank Valves
Fine-Filter
Left
Transfer-Pump
Coarse-Filter
Drainer
Pressure-Dierence-Sensor
Air-Box-Pressure
Fuel-Pressure
Quick-Disconnect- Fittings
Check-Valves
Right
Transfer-Pump
Main-Fuel Pump
Fuel-Shut-O-Valve
Aux-Fuel Pump
Pressure- Regulators at Carburetors
Engine-Compartment
Air-Box
Left Fuel Tank
Fuel-Tank-Vents
Drainer
Sump
Coarse-Filter
Sump
Check-Valve Check-Valve
Fine-Filter
