DOCUMENT NUMBER:
L500-912.820 ISSUE JUL 20, 2016
AMENDMENT: 00
DATE: 
CHAPTERPAGE 338
MAINTENANCE MANUAL STEMME S12
Figure 3.7.a
Electrical System S12
MAIN SYSTEM
COM / NAV
TRIM
LAND. GEAR
LIGHTS
AUTOPILOT
AUX.FUEL PUMP
ENGINE SYSTEM
ENGINE MAIN AND
TRANSFER FUEL PUMP
ENG MONITOR
TCU
PROP PITCH CTRL.
INT. GEN
START
ENGINE
SYSTEM
BATTERY
EXT. ALT
MAIN
SYSTEM
BATTERY
