Steris 4085 - Page 109

6-7
764333-766
Figure 6-6. Articulation Adjustment Screws
NOTE: Turning the adjustment screw CW results in an
audible drop in pitch (speed) of the pump motor.
Port T
Port P
Y11 – Kidney Up
Y21 – Back Up
Y31 – Leg Up
Y41 – Height Up
Y51 – Trend
Y61 – Tilt Right
Y12 – Kidney Down
Y22 – Back Down
Y32 – Leg Down
Y42 – Height Down
Y52 – Rev Trend
Y62 – Tilt Left
Adjustment Screw – Tilt Right Speed
