Steris 4085 - Figure 2-6. STERIS 4085 General Surgical Table Image Amplification Coverage

2-9
Important User Information Operator Manual 150832-639
Figure 2-6. STERIS 4085 General Surgical Table Image Amplification Coverage
25”
(635mm)
13”
(330mm)
43”
(1090mm)
43”
(1088mm)
13”
(330mm)
25”
(637mm)
Column
Column
25”
(635 mm)
13”
(330 mm)
43”
(1090 mm)
43”
(1088 mm)
13”
(330 mm)
25”
(637 mm)
Dimensions are inches (mm). SAE measurements
are approximate based on metric dimensions.
