Steris 4085 - 4.3 Reverse Patient Orientation; 4.4 Optional Foot Control Operation; 4.5 Backup (Override) Control System

4-7
Operating Instructions Operator Manual 150832-639
When Reverse Orientation button is pressed, all other hand control
commands (through the control system) note the new patient head
position. Trendelenburg and Lateral Tilt movements and Back and
Leg Sections are automatically reversed.
IMPORTANT:When using the Reverse Orientation button, note the
following:
1) The information displayed on the LCD is NOT reversed.
2) When table is turned OFF, control system stores orientation
status. Before any new positioning is attempted, ensure table
patient configuration is correct.
3) The STERIS 4085 General Surgical Table Head Section is
manually adjusted and is not affected by Reverse Orientation
button operation.
4) FLEX and REFLEX functions are NOT available for patient
safety.
5) When operating in REVERSE ORIENTATION, LEVEL function
does NOT operate.
6) The hand control automatically deactivates upon nonuse after
30 minutes if floor locks are released and 10 hours when floor
locks are engaged. The hand control is reactivated by
depressing ANY button but STOP.
4.4 Optional Foot
Control Operation
The STERIS 4085 General Surgical Table may be operated using the
optional foot control as follows:
1. Connect foot control cord to appropriate control panel socket on
table column (refer to Figure 3-5).
2. The foot control allows operator to control HEIGHT, TREND and
TILT movements.
3. Press and release any positioning pedal to switch table control
ON. If the hand control is also attached, PEDAL ON appears on
the LCD Display message window.
NOTE: When using the hand control and optional foot control at
the same time, the hand control has priority. Also, if the hand
control STOP button is pressed, foot control also switches OFF.
4. If foot control is unplugged from table, ENSURE protective cover
is placed over opening.
4.5 Backup (Override)
Control System
The STERIS 4085 General Surgical Table is equipped with an
auxiliary control system. This system can be actuated at any time
and allows table operation in the event of primary control
malfunction. A pedal (foot pump to provide hydraulic power) and
override hand control (see Figure 4-4 and Figure 4-6) are located on
the right side of the table base behind a cover panel and are used
for table movements.
NOTE: The STERIS 4085 General Surgical Table head section must
be manually adjusted.
