5. 230 V Power Supply Variation:
The 120 V power supply shows the battery
charge level on the bar graph when on battery
power. But, the 230 V power supply only
shows the battery charge level on the bar graph
when the system is operating on facility (ac)
power. When the system is operating on bat-
tery power, the Hand Control icon indicates
the battery charge level in three stages: Full,
Half and Empty.
* Software is NOT downloadable.
†
Requires Cmax 110 Flash Loader to download.
‡
Requires Cmax Service 1.8 or higher to download.
3.5 TECHNICAL DRAWINGS
Located at the end of this manual (behind the tab
Reference Drawings
) are the STERIS 4085 General
Surgical Table reference drawings. These drawings are
supplied as an aid in understanding unit operation and
troubleshooting.
Table 3-1. STERIS 4085 General Master Control and
Hand Control Assembly Compatibility Matrix
Master Control
Assembly
Software
Versi on
Hand Control*
Hard Plastic
Housing
(P150832-632)
P542200-903
†
1.43 Y
P542200-903
†
1.46 Y
P542200-903
†
1.47 Y
P542200-903
†
(NLA)
1.48 Y
P150832-769
‡
2.04 Y
To Next Page
General
