DESCRIPTION
10
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
1 4085 Surgical Table Plastic Shroud and Support Assembly ....... X
4085 Surgical Table Stainless-Steel Shroud and Support
Assembly ....................................................................................... X
1 P 150832 647 BASE, Cover ........................................................................................ 1 –
2 P 150832 520 COVER, Base, Short, SS (Head) ........................................................ – 1
3 P 150832 519 COVER, Base, Long, SS (Foot) ........................................................... – 1
4 600990 070 SCREW, Button Head Cap, M5 x 12 SS.............................................. 21 21
5 631600 011 WASHER, Nylon, M5 ........................................................................... 4 4
6 Not Used
7 P 150832 648 INSERT, Base Cover (Patient Left)...................................................... 1 –
8 R 005300 568 RTV, 123 Black Sealant (10 oz Tube).................................................. A/R A/R
9 P 150832 663 LABEL, ID 4085 Surgical Table............................................................ 2 2
10 P 150832 630 * PACK, Column Plastic Cover ............................................................... 1 –
P 150832 518 * PACK, Column Stainless Steel Cover.................................................. – 1
11 P 150830 708 SCREW, Flat Head Cap, M5 x 50 ........................................................ 1 –
12 P 150830 688 SPACER............................................................................................... 1 –
13 Not Used
14 Not Used
15 542200 266 * ASSEMBLY, Column Plastic Cover .................................................... 1 1
16 600990 079 SCREW, Button Head Cap, M5 x 10 SS.............................................. 10 10
17 542200 052 * COVER, Saddle Plastic (2-Piece) ........................................................ 1 1
18 600410 408 SCREW, Fillester Head Cap, M4 x 8 SS (Hinge)................................. 10 10
19 542200 053 COVER, Chain .................................................................................... 1 1
20 P 150832 391 COVER, Translation-Right (Non-Hinged)............................................. 1 1
21 P 150832 390 COVER, Translation-Left (Non-Hinged)............................................... 1 1
22 P 150832 524 SCREW, Button Head Cap, M5 x 30 SS.............................................. - 2
23 P 150832 632 4085 HAND CONTROL (Without Cable).............................................. 1 1
24 542200 420 CABLE, 4085 Hand Control ................................................................. 1 1
25 542200 211 CABLE, HC Harness Connector Plate Assembly................................. 1 1
26 542200 411 * ASSEMBLY, Column Support ............................................................. 1 1
27 600530 510 SCREW, Socket Head Cap, M5 x 10 SS ............................................. A/R A/R
28 602181 652 WASHER, Fender, M5 SS ................................................................... 4 4
29 P 150832 151 CRATE, Shipping (Not Shown) ............................................................ 1 1
30 P 150832 664 LABEL, Weight Limit ............................................................................ 1 1
31 Not Used
32 P 150832 525 SPACER, Base Cover.......................................................................... – 2
33 R 007200 964 TAPE, Foam, 1/4 x 3/4 (Shown on 1 of 2, Not on 2 of 2) ..................... A/R A/R
34 R 007200 965 TAPE, Foam, 1/2 x 3/4 (Not Shown) .................................................... A/R A/R
* Individual part not available.
