Steris 4085 - Page 147

S
V
C
DESCRIPTION
15
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
2 4085 Surgical Tabletop .................................................................... X
1 P 755717 643 ** ASSEMBLY, Back Rail-Left ................................................................. 1
2 P 755717 644 ** ASSEMBLY, Back Rail-Right............................................................... 1
3Not Used
4Not Used
5 COVER, Translation (See Figure 1) .................................................... –
6 P 755717 645 ** ASSEMBLY, Leg Rail-Left ................................................................... 1
7 P 755717 646 ** ASSEMBLY, Leg Rail-Right................................................................. 1
8 P 755717 641 ** ASSEMBLY, Seat Rail-Left.................................................................. 11
9 P 755717 642 ** ASSEMBLY, Seat Rail-Right ............................................................... 1
10 600411 035 SCREW, Fillester Head Cap, M10 x 35 SS ......................................... 12
11 Not Used
12 P 150832 389 SCREW, Flat Head Cap, M8 x 60........................................................ 2
13 600410 835 SCREW, Fillester Head Cap, M8 x 35 SS ........................................... 2
14 542200 100 SPACER .............................................................................................. 16
15 Not Used
16 Not Used
17 P 150832 388 SPACER .............................................................................................. 2
18 542200 094 COVER, Lateral Right (Seat Section)................................................. 1
19 542200 095 COVER, Lateral Left (Seat Section) .................................................... 1
20 600410 408 SCREW, Fillester Head Cap, M4 x 8 ................................................... 4
21 ASSEMBLY, Headrest (See Figure 7)................................................. 1
22 P 755718 169 TABLETOP, Headrest.......................................................................... 1
23 P 755718 172 TABLETOP, Back Section Top ........................................................... 1
24 P 150832 218 TABLETOP, Kidney Bridge Section..................................................... 1
25 P 755718 171 TABLETOP, Seat Section Top............................................................. 1
26 P 755718 170 TABLETOP, Leg Section Top.............................................................. 1
27 542200 816 SET, 4085 Table Pads Complete, 2-1/4 Thick .................................... 1
P 150832 695 • PAD, Headrest Section ..................................................................... 1
413724 464 • PAD, Back/Seat Section.................................................................... 1
413724 465 • PAD, Leg Section .............................................................................. 1
28 P 150832 560 * ASSEMBLY, Headrest X-Ray Top ...................................................... 1
P 150832 552 • TOP, Headrest X-Ray ...................................................................... 1
29 413724 533 * ASSEMBLY, Back Section X-Ray Top ................................................ 1
P 150832 554 • TOP, Back Section X-Ray ................................................................ 1
30 P 150832 562 * ASSEMBLY, Seat Section X-Ray Top ................................................. 1
P 150832 556 • TOP, Seat Section X-Ray ................................................................. 1
31 P 150832 563 * ASSEMBLY, Leg Section X-Ray Top .................................................. 1
P 150832 558 • TOP, Leg Section X-Ray ................................................................... 1
32 413724 527 ASSEMBLY, Spacer ........................................................................... 12
33 Not Used
34 P 077643 056 STANDOFF (Surface).......................................................................... 2
35 P 764329 992 KIT, Hook Fastener, 5 Ft...................................................................... A/R
36 P 150832 240 SCREW, Slotted Pan Head, M6 x 12mm............................................. 44
37 P 150055 001 SCREW, Slotted Pan Head, 1/4-20 x 7/8 ............................................ 36
38 KNOBS, Locking (See Figure 3).......................................................... –
