Steris 4085 - Page 160

To Next Page

To Previous Page

DESCRIPTION

764333-767

FIG. &

ITEM

NO.

PART

NUMBER

UNITS PER

ASSEMBLY

5 4085 Table Base Assemby With Plastic Shrouds ........................ X

4085 Table Base Assemby With SS Shrouds................................ X

71 342213 555 SET, Fuse (Not Shown) ....................................................................... 1 1

• FUSE, Main 6, 3A T (F6/7) ................................................................ 4 4

• FUSE, Battery, 16A (F8).................................................................... 2 2

• FUSE, Battery Charger, 4A T (F1)..................................................... 2 2

• FUSE, Battery Charger, 12A T (F3/4)................................................ 2 2

• FUSE, Battery Charger, 15A T (F2)................................................... 2 2

72 Not Used

73 P 026962 061 WASHER, Belleville, 1/4 ...................................................................... 1 1

74 P 150832 340 HARNESS, 4085 Foot Control ............................................................. 1 1

75 P 150832 353 FLOOR LOCK, Control Box Assembly................................................. 1 1

76 P 150832 388 SPACER, .472 Long............................................................................. 2 2

77 P 150832 418 MANIFOLD ASSEMBLY, Floor Lock.................................................... 1 1

78 P 150832 419 SPACER, Manifold, Floor Lock ............................................................ 1 1

79 P 150832 543 SCREW, Socket Head Cap, M5 x 40 SS ............................................. 2 2

80 P 431117 091 WIRE TIE, .041 x .140 x 8.0 (Not Shown)............................................ A/R A/R

81 600530 608 SCREW, Socket Head Cap, M6 x 8 SS ............................................... 1 1

82 600530 640 SCREW, Socket Head Cap, M6 x 40 SS ............................................. 2 2

83 342291 555 PACK, Hydraulic Screw Parts .............................................................. A/R A/R

• SCREW, Single Way Small Hydraulic (Qty. 10) ................................ – –

• WASHER, Small Sealing (Qty. 20) .................................................... – –

• SCREW, Single Way Small Hydraulic (Qty. 10) ................................ – –

• BOLT, Banjo, M10 x 100 (Qty. 10) .................................................... – –

• WASHER, Sealing (Qty. 50) .............................................................. – –

84 P 150832 657 ** SHIM, Caster........................................................................................ A/R A/R

85 P 150832 710 * PACK, Spacer Mayo Stand Parts......................................................... A/R A/R

86 P 150832 659 RELIEF, Strain ..................................................................................... 1 1

* Item #85 is needed if the Mayo Stand needs additional Clearance

between Table Base and floor.

**Item #84 Caster Shims are used as required to level table on

unlevel floors.
