Steris 4085 - Page 167

S
V
C
DESCRIPTION
39
764333-767
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
6 P 150832 559 4085 Surgical Table Headrest Aassembly...................................... X
1 * FRAME, Headrest LH, 4085 ................................................................ 1
2 * FRAME, headrest, RH, 4085 ............................................................... 1
3 P 150823 276 SPACER, Siderail, 9/16 ....................................................................... 4
4 P 150832 379 CAP PIVOT, Chrome Painted.............................................................. 2
5 P 056397 899 SIDE RAIL, Bent Headrest, LH............................................................ 1
6 * BLOCK, Support RH, 4085.................................................................. 1
7 * BLOCK, Support LH, 4085................................................................... 1
8 P 134469 493 PAWL, 3085 Headrest ......................................................................... 1
9 P 093909 191 RATCHET, Headrest ........................................................................... 1
10 P 129360 253 SHAFT ................................................................................................. 1
11 P 129360 249 SLEEVE, Bearing................................................................................. 2
12 P 755718 169 ASSEMBLY, Head Section Top, 4085................................................. 1
13 P 056397 898 HANDLE, Flat Head Rest .................................................................... 1
14 P 150832 374 SHAFT, Headrest, 4085....................................................................... 2
15 P 129360 230 BUMPER, Rubber................................................................................ 2
16 P 129360 228 SPRING, Compression........................................................................ 4
17 P 129360 229 STOP, Nylon ........................................................................................ 4
18 P 129360 255 WASHER, Spring................................................................................. 1
19 P 129360 258 SCREW, Shoulder, 8-32 x 3/16 x 1 ..................................................... 4
20 P 129360 353 SPRING, Compression........................................................................ 1
21 P 083755 001 SCREW, Shoulder, 5/16-18 x 3/4 ........................................................ 1
22 P 081222 001 SCREW, 8-32 x 7/8 Socket Head Cap, SS.......................................... 2
23 P 150832 223 SCREW, Pan Head, M6 x 20mm......................................................... 4
24 P 150473 302 WASHER, Flat, #8 ............................................................................... 4
25 Not Used
26 P 150830 110 SETSCREW, #8-32 x 15/64................................................................. 1
27 P 010456 091 WASHER ............................................................................................. 4
28 P 129360 256 WASHER, Thrust................................................................................. 1
29 P 036565 061 ROLL PIN, 1/8 Dia. x 1 ........................................................................ 3
30 P 031276 061 SETSCREW, 10-32 x 1/2 HSC............................................................ 1
31 P 129357 095 SCREW, 5/16-18 x 1-1/4 FH................................................................ 6
32 P 056397 900 SIDE RAIL, Bent Headrest, RH ........................................................... 1
33 P 129180 173 PIN, Roll............................................................................................... 1
34 P 129359 894 TAPE, Adhesive................................................................................... 2
35 R 005300 542 LOCTITE
®1
, 609-31, BRG Retain (Not Shown) ................................... A/R
36 R 005300 545 LOCTITE, Sealant, #222-31 ................................................................ A/R
37 P 764329 992 KIT, Hook Fastener (5 Feet) ............................................................... 1
38 R 005300 912 LOCTITE, Primer T 7471, (Not Shown)............................................... A/R
