Steris 4085 - Fig & Item # 7

Fig &
Item #
Part
Number
N
ot
e
s
Desc.
7
413724-543 LEG SECT ASSY Cmax/4085/5085 General X
7
P150832-760 ***
LEG SECT ASSY, Featherweight Cmax/4085/5085 General (Not Shown)
X
1
* ASSEMBLY, RT LEG SECTION. MEMBER 1
2
* ASSEMBLY, LEFT LEG SECTION MEMBER 1
3
624900-014 BRING,SLEEVE 14 MM 2
4
624900-015 BEARING, SLEEVE 8MM # 6 2
5
542200-143 WASHER , Friction Disc 2
6
542200-145 LEFT LOCKING SHAFT 1
7
542200-144 RIGHT LOCKING SHAFT 1
8
542200-146 END STOP 2
9
542200-147 RIGHT SPRING 1
10
542200-148 LEFT SPRING 1
11
542200-149 RELEASE HANDLE 2
12
603000-416 DOWEL PIN M4 X 16 2
13 600530-410
SCREW,SOCKET HD CAP M4 X 10,SS 4
14
600530-425 SCREW, SHC M4 X 25 SS 2
15
602321-682 FLAT WASHER, M8 SS 2
16
P755718-170 ASSY,LEG 4085/5085/SRT 1
17
P150832-270 SUPP,BLK INSRT RH LEG SEC 1
17
P150832-762 SUPP,BLK 5085 SRT RH LEG -
18
P150832-269 SUPP,BLK INSRT LH LEG SEC 1
18
P150832-761 SUPP,BLK 5085 SRT LH LEG -
19
542200-100 SPACER, SIDERAIL 6
20
P755717-646 RAIL,SIDE RH LEG-CMAX/4085/5086 1
21
P755717-645 RAIL,SIDE LH LEG-CMAX/4085/5085 1
22
600411-030 SCREW, FHC M10 X 30 SS 2
23
600411-035 SCREW, FHC M10 X 35 SS 4
24
P764329-992 FASTENER, HOOK 5' WITH INSTRUCTION A/R
25
P150832-223 SCREW, PAN HD M6 X 20MM 16
26
P009645-061 ** SCREW, DRIVE #4 X 3/16 LG (NOT SHOWN) 2
27
P051112-061 ** CAM SIDE RAIL (NOT SHOWN) 2
28
P043224-061 ** PIN ROLL 3/32X3/8 LG (NOT SHOWN) 2
29
P077559-056 KNOB ASSY PLASTIC 2
30
P150832-435 SCREW, SSSCP M4 X 8 2
* Not available at this time.
** Items 26,27 & 28 are included with item 20 & 21.
***
No service replacement parts available, unit must be replaced.
Quantity
