150832-639 Operating Manual Safety Precautions
Floor Locks Unlocked (Orange).
ALS Notification (ICON and Text).
Maintenance Notification (Blue).
Kidney Bridge (Blue).
Keypress (Green).
Slide in Head Direction (Blue).
Slide in Foot Direction (Blue).
Slide Displayed in Inches (Blue).
Slide Displayed in Centimeters (Blue).
Table 1-3. Definition of Hand Control LCD Display Screen Icons (Cont’d)
Symbol Definition
