CAUTION – POSSIBLE EQUIPMENT DAMAGE (CONT’D):
REMEMBER – POSSIBLE TIME DELAY:
When the bearing assembly is removed from the table, the seat section side member becomes free-
floating. Be careful not to damage the slide potentiometer pulley that sits freely in the groove in the seat
section side member.
Do not remove the bearing cartridges from the bearing rail. Damage may result to the cartridge and/
or loss of the ball bearings upon reinsertion into the cartridges.
Always connect power cord to a properly grounded socket.
Isolate the coil and/or pump motor from the control by disconnecting the wires on the motor terminal
board, or slip the wires off the solenoid coil.
Insufficient clearance space will make repairs more difficult and time-consuming. Refer to the equipment
drawing for minimum clearance for service/maintenance access requirements.
