6. Table does not function on facility
power (power cord plugged into
appropriate facility power and battery
fuse F8 removed, or battery charge too
low) but table does function on battery
power.
• Batteries accept charge (power cord
plugged into facilty power).
• INTELLIPOWER Display Battery
Status Indicator functions when on
battery power and ac Power Plug
Indicator functions when power
cord is plugged into appropriate
facility power.
• Control power fuse F2
open.
• Replace control power fuse F2.
7. Table does not slide and Floor
Locks do not engage/disengage.
• Otherwise, table functions on both
facility and battery power.
• Batteries accept charge.
• Slide control power fuse
F3 open.
• Replace slide control power fuse F3.
8. Hydraulic pump does not operate
but table slide functions (if Floor
Locks are engaged).
• Hydraulic pump power
fuse F4 open.
• Replace hydraulic pump power fuse F4.
9. Batteries do not charge.
• Table functions on battery power.
• Table functions on facility power.
• Main Power Switch (if equipped
with backlight) glows green when
power cord is plugged into
appropriate facility power and
switch is ON.
• Battery charge power
switch (Main Power
Switch) open.
• Line fuses F6/F7 open.
• Close Main Power Switch.
• Replace line fuses F6/F7.
10. Hydraulic fluid reservoir shows a
loss of fluid but no external leaks
found.
• Height cylinder leaking
into column tube.
• Inspect inside of column tube for
hydraulic fluid. If loose banjo fitting is
found, replace banjo fittings and sealing
washers.
• Still leaking, replace column cylinder,
bajo fittings and sealing washers.
11. Hand Control Display goes blank
during Master Control program
download process.
• Faulty download cable/
connection.
• Faulty table control board.
• Verify downloading cabling is correct.
• Replace table control board.
Table 5-1. Troubleshooting Guide (Cont’d)
Situation Cause Service Instructions
