7 Special equipment
Acoustic warning signal
Acoustic warning signal
Asanoption,thesetruckscanalsobefitted
with an acoustic warning system as an addi-
tional safety measure.
The signal is given according to the direction
of travel or speed.
Tilt barrier
Description
When in a reclined positi
on, the tilt barrier
opens out to the side towa
rds the racking.
This means that the dist
ance to the racking
is reduced, which facil
itates order picking.
If the operator release
s the tilt barrier, it is
automatically returne
d to the initial position by
spring force.
The tilt barrier consists essentially of a mobile
upper part, a fixed bottom part and a hinge
connecting the upper and bottom parts. For
safety reasons, the tilt barrier is unlocked only
under certain conditions.
Function
The barrier can only be opened if:
• The truck is in an aisle
• The barriers are closed
• The two-hand sensors are not actuated
• The operating levers for driving/hydraulics
are in the neutral position
• The foot switch is not actuated
• The driving speed is v < 0.1 km/h
The barrier will be locked if:
• One of the barriers is opened
• The foot switch and the drive operating lever
is actuated
• The main lift function is selected
• The truck is not in an aisle
NOTE
If the truck is in an aisle and one of the two
barriers is opened and then closed again, the
10
6 5213 804 2501 EN - 01/2016
