Overview 3
View into the control compartment
View into the control compartment
1 Control current fuses
2 Programming interface
3 Main current fuse for steering
4 Main current fuse for driving and pump
5 Truck control unit
6Horn
7 Electromagnetic brake
8 Steering motor
9Tractionmotor
10 Steering gears and gearbox
11 Collision protection
12 Hydraulic oil tank
13 Hydraulic oil filter
14 Hydraulic oil filling opening
15 Emergency lowering valve
16 Pump motor
17 Battery connector
18 Direction indicator
52
13 804 2501 EN - 01/2016 35
