4 Operation
Load pick-up
1 Auxiliary lift preselection
2 lifting
3 lowering
4 not assigned
Auxiliary lift, load-side operation
These trucks can optionally be equipped with
load-side operation for the auxiliary lift.
1 Infinitely variable lowering, simultaneous
contact with the steering knob or steering
wheel
2 Infinitely variable lifting, simultaneous
contact with the steering knob or steering
wheel.
Load pick-up with automatic guid-
ance
Order pickers are designed primarily for the
collection or distribution of goods in containers
or on pallets. The depositing and removal of
loads are not possible in narrow aisles. During
transport, the additional lift* must be lowered
on principle.
DANGER
Danger of tilting forward
As a result of the order picking process, transpor-
ted loads are collected and so increasing weight
accumulated on the load carrier. As this is a manu-
ally performed process, it cannot be monitored by
the truck control system, which is consequently not
able to issue a warning in case of overloading. The
operator is required to ensure that the load bearing
capacity of the order picker is not exceeded.
68
5213 804 2501 EN - 01/2016
