Operation 4
General commissioning
Battery lock
Battery lock for wide chassis
The battery lock is electronically monitored
(1). If this monitoring function detects an error,
the driving speed of the truck is limited to 2.5
km/h and an error message appears on the
display.
Battery lock for narrow chassis
In trucks with a narrow chassis, the battery is
secured with a lock located above the battery.
To lock the battery securely, push both levers
downwards.
NOTE
Before starting work, check whether the
locking plates are pressed against the battery
without any play. If this is not the case, the
authorised service centre can adjust the
locking device.
52
13 804 2501 EN - 01/2016 49
