Operation 4
Emergency operation
Emergency operation
Emergency operation
If the entire truck control unit fails or if part of it
fails, the truck can be moved out of the working
area by means of the relevant emergency
operation.
Opening the control compartment cover
– Rotate the two screw plugs on the cover
anti-clockwise and remove them.
– Hold the cover at the venti
lation openings,
lift it off and then place t
o one side. The
lowering valve is locate
d in the control
compartment and can be ac
cessed once
the control compartment
cover has been
opened.
– Rotatethewingscrew(1)onthevalveblock
anti-clockwise. The lowering procedure
begins.
– Do not adjust any screws other than the
wing screw on the emergency lowering
valve.
52
13 804 2501 EN - 01/2016 71
