Operation 4
General commissioning
Replacing the battery
Open battery compartment cover
The battery compartment cover can be
opened by lifting it sideways against the lift
mast. A special hinge system guides the
cover.
For maintenance work, the c
over can be
removed completely.
Battery compartment door*
Side battery compartment doors can be built
in as an option. To open the doors, turn both
latches 90°.
After reinserting the battery compartment
doors, lock both latches again securely.
*Option
52
13 804 2501 EN - 01/2016 47
