5
Figure 2 Interior chamber - front view
1Extrusion Head
2 Tip wipe assembly
3Purge bucket
4 Z stage platen
5 Modeling base retainers (x2)
6Modeling base
7Z stage lead screw
8Z stage guide rods
9Extrusion Tips
2
5
3
4
6
7
8
9
1
