Technical user manual V1.3 © Studer-Innotec SA 55
2x
exceeding the source maximum allowed power
3x
phases order is incorrect, or one phase is missing
4x
source has other warning(s) or error(s) (please see
the nx-interface for details)
4a
AC-Flex as a
source
indicator
(genset symbol)
(house symbol is
permanently OFF)
permanently OFF
source is deactivated, or not present
permanently ON
source is connected and working properly
1x
source is present but next3 is in waiting procedure
for connection
2x
exceeding the source maximum allowed power
3x
phases order is incorrect, or one phase is missing
4x
AC-Flex has other warning(s) or error(s) (please see
the nx-interface for details)
4b
AC-Flex as a load
indicator
(house symbol)
(genset symbol is
permanently OFF)
permanently OFF
loads are not powered
permanently ON
loads are properly powered
1x
standby / load search mode
2x
AC-Flex has other warning(s) or error(s) (please see
the nx-interface for details)
5
AC-Loads
indicator
permanently OFF
loads are not powered
permanently ON
loads are properly powered
1x
standby / load search mode
2x
loads have other warning(s) or error(s) (please see
the nx-interface for details)
6
Battery
indicator
permanently OFF
battery is disconnected, next3 is not powered up
permanently ON
battery works properly
1x
battery is almost empty
2x
battery has other warning(s) or error(s) (please see
the nx-interface for details)
7
Solar
indicator
permanently OFF
solar is deactivated or not present
permanently ON
solar is producing properly
1x
Night or dawn/dusk
2x
no solar production since 48h
3x
solar has other warning(s) or error(s) (please see the
nx-interface for details)
State of charge indicator: 4 bars in the battery symbol:
• 75 to 100 %
• 50 to 75 %
• 25 to 50 %
• 0 to 25 %
In charge mode, the upper LED line inside the battery blinks indicating the charge phase:
• 1 time: bulk
• 2 times: absorption
• 3 times: equalization
• permanently on: floating
For lithium batteries with BMS, the upper line never blinks as there are no charging phase controlled
by the next3. The charge is controlled by the BMS.
Special cases:
• If there is absolutely no light on any of the LEDs, the next is completely without power (battery
disconnected) or there is a problem with the display of LEDs.
• When powering up the next3 with the battery, all LEDs blink once during the start check.
• All LEDs can blink at the same time in an identification procedure (with nx-interface). It is
possible to identify the devices in multi-unit system that way:
