3-14 SPARC Enterprise Mx000 Servers XSCF User’s Guide • August 2009
FIGURE 3-4 shows the intranet connection.
FIGURE 3-4 Intranet Connection (In a High-End Server)
When you use the XSCF Shell, you can have high security by using SSH not telnet.
The XSCF Web uses SSL to provide authentication security.
SSH/telnet/
https
connection
Mail
Notification
Router
Basic cabinet
XSCF-LAN port
Serial port
Intranet
Terminal
User
LAN
User
LAN
DomainID x
DomainID y
DomainID m
DomainID n
XSCFU
#0
XSCFU
#1
Terminal
SSH/telnet
https
connection
