Sun Microsystems Sun SPARC Enterprise M5000 - FIGURE 2-1 Network Interface Required for XSCF Network Configuration (in the High-End Servers)

Chapter 2 Setting Up XSCF 2-19
FIGURE 2-1 Network Interface Required for XSCF Network Configuration (In the
High-End Servers)
7,8; Addresses of Inter SCF Network(ISN)
Inside LAN
Ethernet
1-6; Addresses of XSCF-LAN
9,10,..,10+X; Addresses of DSCP links
1
2
3
4
5
6
7
8
XSCFU#0
XSCFU#1
#0
#0
#1
#1
Server
DomainID X
DomainID 0
DomainID 1
9
9
10
11 10+X
