2-20 SPARC Enterprise Mx000 Servers XSCF User’s Guide • August 2009
XSCF network configuration procedure and the reference
The procedure to set up the XSCF network is as follows. Each step offers the detailed
procedure reference.
Note – You must set XSCF-LAN, ISN, and DSCP to different subnet addresses. If
two XSCF-LAN ports are used, each must be assigned to a different subnet. The ISN
address has been set up with the default value (see TABLE 2-2).
1. Specify the IP address of Ethernet (XSCF-LAN).
You can use two XSCF-LAN ports in accordance with the network configuration. In
the M3000/M4000/M5000 servers, specify either or both of the following IP
addresses:
â– XSCF-LAN#0 of XSCFU#0 (See "1" in FIGURE 2-1)
â– XSCF-LAN#1 of XSCFU#0 (See "4" in FIGURE 2-1)
In the M8000/M9000 servers, subsequently to the XSCFU#0 side, specify the IP
address of XSCF-LAN of the XSCFU#1 side (see "2" and "5" in
FIGURE 2-1). (See
shownetwork (8), setnetwork (8).)
Use the same subnet address to specify the LAN ports which share the same number
in each XSCF unit so that you can connect to both of the XSCF in case the XSCF
failover generated.
Number Description Number Description
1 XSCF-LAN#0 address
(XSCFU#0 side)
7 ISN address.
(XSCFU#0 side)
2 XSCF-LAN#0 address
(XSCFU#1 side)
8 ISN address.
(XSCFU#1 side)
3 Takeover IP address
between XSCF-LAN#0s
9 DSCP link address
(XSCF side)
4 XSCF-LAN#1 address
(XSCFU#0 side)
10 or
later
DSCP link addresses
(Domains side)
5 XSCF-LAN#1 address
(XSCFU#1 side)
6 Takeover IP address
between XSCF-LAN#1s
To Next Page
