9-2 SPARC Enterprise Mx000 Servers XSCF User’s Guide • August 2009
The following figures show examples of these pages in a web browser.
TABLE 9-1 XSCF Web Pages
Basic Page Description
Login page XSCF Web console login page. Log in with an XSCF user account from the login
page.
Masthead frame The page on the upper part of the screen. The masthead frame displays the user
account name specified at login, the connected host name, and so on. When you
log out from the masthead frame, you are returned to the login page.
Menu frame
(Tree frame)
In the page displayed by default after login, there is a frame of the tree navigator
to select each page.
There are the following three kinds of tree navigators.
- Menu; The menu of various settings, operations, and state displays that are
displayed in the tree.
- Physical; Physical components of the server are displayed in the tree
- Logical; Logical components of each domain are displayed in the tree
Main page A generic name of the detailed page located at the right of the screen. When you
select an item from the menu in the tree frame, the target page is displayed here.
Event frame
(Monitor message frame)
A page that displays the monitoring message located under the screen.
Frame displaying the entire system events.
As for the monitor message frame, the content of the display is regularly
refreshed. An initial value at refreshing intervals is 60 seconds. You can change
the interval value on the same frame.
Status display Page displaying the status of the entire system and the domain status. The page
display includes the External I/O expansion Unit status.
System/domain operation Page for operations for the entire system and individual domains. When a setting
item is selected by the menu, a target page is displayed. The pages include pages
for power operations, domain configuration management, and DR operations.
XSCF settings Pages for making XSCF operation settings. When a setting item is selected by the
tree frame menu, a target page is displayed.
Utility pages Pages such as firmware update, remote maintenance service, XSCF reset, and
XSCF switch (M8000/M9000 servers only).
Log display Page displaying logs. Error logs, power logs, event logs, console logs, and other
logs are displayed.
Standby side page
(M8000/M9000 servers only)
Page is displayed when you login to standby Unit.
This page is included for XSCF switch and log collection.
