Hammer drill
(φ10)
Marker Vacuum cleaner Rubber mallet
Wrist strap Wire cutter Wire stripper Hydraulic plier
Heat gun MC4 terminal
crimping pliers
4–6mm
2
MC4 terminal
wrench
Multimeter
≥ 1000V DC
Wrench
(16 mm, 46 mm)
RJ45 crimping tool
5.4 Moving the Inverter
Before installation, remove the inverter from the packing case and move it to the installation
site. Follow the instructions below as you move the inverter:
• Always be aware of the weight of the inverter.
• Lift the inverter using the handles positioned on both sides of the inverter.
• Move the inverter by one or two people or by using a proper transport tool.
• Do not release the equipment unless it has been firmly secured.
5 Mechanical Mounting User Manual
