Sungrow SH5.0RT - AC Cable Connection; AC Side Requirements

38
(1) Heat shrink tubing (2) OT/DT terminal
step 2 Remove the screw on the grounding terminal and fasten the cable with a screwdriver.
step 3 Apply paint to the grounding terminal to ensure corrosion resistance.
- - End
6.5 AC Cable Connection
6.5.1 AC Side Requirements
Connect the inverter to the grid only after getting an approval from the local elec-
tric power company.
6 Electrical Connection User Manual
