SunSynk 8kW User Manual

Website: www.sunsynk.com E-mail: sales@globaltech-china.com
17
3. INSTALLING THE SUNSYNK INVERTER
3.1. MOUNTING THE INVERTER
If you are now familiar with the inverter and how it functions and are a licensed electrical engineer, you
are ready to install one of our amazing machines.
Be careful about choosing the location to mount the inverter. Please refer to the User Manual for the best
mounting position and location.
Figure 12 – Keith Gough at a Sunsynk installation in Port Elizabeth.
IMPORTANT:

Do not fit the inverter in any area where it is going to be too hot, and the environmental temperature is too
hot or humid. These conditions can cause the inverter to overheat, so additional air conditioning or
ventilation may be required.

Ensure that the inverters are mounted securely on the wall.

When using multiple-inverters, try to keep them a metre apart, because if they get very close to each
other, it may reduce ventilation and affect the cooling system of the inverter.

For more information, refer to the User Manual.
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com
Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com

SunSynk 8kW Specifications

General

Rated Power	8kW
Max. DC Voltage	500V
Number of MPPTs	2
Max Output Current	35A
Max Efficiency	97.6%
Battery Voltage	48V
Max Charging Current	190A
Max Discharging Current	190A
Frequency	50/60Hz
Max PV Input	10400W
Operating Temperature	-25°C to 60°C
Protection Rating	IP65
Max DC Input Voltage	500V
Max Input Current	22A
Nominal AC Voltage	230V
Communication	RS485
Protection	Overload Protection
Cooling	Fan
