SunSynk 8kW User Manual

Website: www.sunsynk.com E-mail: sales@globaltech-china.com
49
This is very useful in grids with massive surplus charges for overuse of energy or in areas where you have
a limited power supply. For example, you may only have a 10A supply, but you may require 20A, 30A, or
more. Therefore, the inverter can be used to take up the exceeding power when it is required.
For peak shaving applications, the CT coil is used to measure the load on the system and to supply the
extra power when needed.
On the Aux Load page, you can select the level when the power shaving starts and the amount of power
that the inverter will deliver. Also, do not forget that you need to set the global inverter level on the controller
page.
Figure 46 - Peak shaving setting.
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com
Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com

SunSynk 8kW Specifications

General

Rated Power	8kW
Max. DC Voltage	500V
Number of MPPTs	2
Max Output Current	35A
Max Efficiency	97.6%
Battery Voltage	48V
Max Charging Current	190A
Max Discharging Current	190A
Frequency	50/60Hz
Max PV Input	10400W
Operating Temperature	-25°C to 60°C
Protection Rating	IP65
Max DC Input Voltage	500V
Max Input Current	22A
Nominal AC Voltage	230V
Communication	RS485
Protection	Overload Protection
Cooling	Fan
