SunSynk 8kW Specifications

General

Rated Power	8kW
Max. DC Voltage	500V
Number of MPPTs	2
Max Output Current	35A
Max Efficiency	97.6%
Battery Voltage	48V
Max Charging Current	190A
Max Discharging Current	190A
Frequency	50/60Hz
Max PV Input	10400W
Operating Temperature	-25°C to 60°C
Protection Rating	IP65
Max DC Input Voltage	500V
Max Input Current	22A
Nominal AC Voltage	230V
Communication	RS485
Protection	Overload Protection
Cooling	Fan
