5. THE DISPLAY
The Sunsynk hybrid inverter has the most amazing navigation and information screens of any other
inverter in its class.
Figure 29 – Amazing interface of the Sunsynk inverter.
Once the inverter has been properly installed and the batteries are connected, press the ON/OFF button
(located on the left side and underneath the case) to turn on the system. Many people often forget to switch
on the inverter.
When the system is connected without a battery but connected with either PV Array or to the Grid and the
ON/OFF button is switched OFF, the LCD will still light up (display will show ‘OFF’). In this condition, when
switching on the ON/OFF button and selecting no battery, the system can still work.
5.1. HOME SCREEN
This is the first screen that you will see when the system is booted up. It is a very useful screen and was
designed to give a lot of information in a small display.
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com Sunsynk.com
Sunsynk.com
Sunsynk.com
Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com Sunsynk.com

SunSynk 8kW Specifications

General

Rated Power	8kW
Max. DC Voltage	500V
Number of MPPTs	2
Max Output Current	35A
Max Efficiency	97.6%
Battery Voltage	48V
Max Charging Current	190A
Max Discharging Current	190A
Frequency	50/60Hz
Max PV Input	10400W
Operating Temperature	-25°C to 60°C
Protection Rating	IP65
Max DC Input Voltage	500V
Max Input Current	22A
Nominal AC Voltage	230V
Communication	RS485
Protection	Overload Protection
Cooling	Fan
