SUNWARD SWE155F - 6 NOTE FOR SAFETY

OPERATION & MAINTENANCE MANUAL SWE155F
170
5.1 SW155F TECHNICAL SPECIFICATION
5.1.1 Machine Specification
Machine
SWE155F
Operation weight
15200 kg
Standard bucket capacity
0.61 m3
Track shoe width
600mm
Power equipment
Engine model
CUMMINS QSF3.8 Stage 5 TC121
Type
Direct injection, water-cooling, four strokes,
supercharge, intercooling
Cylinders
6
BoreｘStroke
102mmX115mm
Displacement
3.8 L
Rated power/rotation speed
90kW/2200rpm
Max. torque/rotation speed
500N.m/1500rpm
Fuel tank capacity
245 L
Hydraulic system
Main pump
2 × piston pump
Flow rate
2×126.4L/min
Work pressure
31.4Mpa
Front work equipment(supercharge)
31.4(34.3) Mpa
Travel
34.3Mpa
Swing
25Mpa
Pilot pump
1×gear pump
Flow rate
20L/Min
Pilot pressure
3.9 Mpa
Hydraulic tank capacity
150 L
Performance parameter
Swing speed
11 rpm
Travel speed
5.3 /3.2 km/h
Max. traction
115 kN
Max. gradeability
35°
Bucket max. digging force
100 kN
Arm max. digging force
76 kN
