OPERATION & MAINTENANCE MANUAL SWE155F
D：Arm rest angle adjustment
Rotate the angle adjustment hand wheel 5 under the arm
rest; adjust the arm rest 4 to the comfortable position.
E：Foot position adjustment
Pull up level 2, and adjust the foot position, after it
attains ideal position, put down the lever, and realize
self-hold.
F：Bearing adjustment
Rotate lever 7, observe the bearing of the seat through
observation window, until the bearing attain to the body
weight of the operator.
3.3.6 Fuse
Note
Always turn off the key switch prior to fuse replacement.
The fuses protect the electrical equipment and wiring from burning out. .
Replace any fuse with corrosion or generating white powder or any fuse looseness in fuse holder.
Replace fuses with equivalent capacity ones.
