OPERATION & MAINTENANCE MANUAL SWE155F
Attention
Set the volume to the appropriate position to avoid traffic
accidents.
Place this radio in the cab if in the hot or cold day. Idle
temperature ensures its good performance.
It's easily broken when water poured in, don't spray water
onto this radio when washing the machine.
3.3.5 Seat
Seat adjustment specification
The seat is two stages adjustable and capable of moving
forward and backward. the adjustment: 270mm
(forward 140mm, backward 130mm)；
The backrest infinite variable adjustment range:
35°-170°；
Seat suspension adjustment: 60mm; the seat infinite
variable adjustment range: 50-130 kg.；
Headrest height adjustment range: 105mm. it’s
adjustable in 7 stages.；
The armrest can be adjusted from -40°~100
Instruction
A：Hand position adjustment
Raise the adjustment lever 1, upper seat move forward
or backward. Adjust hand to proper position.
B: Backrest tilting adjustment
Pull up the adjustment lever 3, turn the backrest (or the
backrest will turn forward automatically). Adjust the
backrest to the optimal position and convenient for
operation, then loose the lever.
C：Seat height adjustment
Lift the seat upward, when you hear the fist click sound,
the seat rise 30mm, lift the seat again, the seat rise
another 30mm, still lift the seat, it will fall down to the
lowest position.
