OPERATION & MAINTENANCE MANUAL SWE155F
2.1.4 Loading
Note
Load the machine only on firm, level ground
and keep a safe distance with the road shoulder.
Chock the machine to prevent the machine
movement during loading process.
The ramp for loading must have enough
strength and width with an maximum slope of
15°, be sure both side of the ramp is at equal
level so that machine could travel safely.
Loading operation
Switch off idle speed, set engine speed to low speed
by means of fuel control knob.
Set travel speed selector to low speed position.
Machine direction ： When loading, if machine is
equipped with working device, keep the working
device at the front of the machine and travel forward.
If no working device, travel in reverse to load the
machine.
Align the direction of the machine with the ramp： be
sure the center line of the machine track matches that
of the ramp and travel slowly.
Lower the working equipment as much as possible
without causing any interference on the machine.
When traveling on slope, operate only the travel lever;
never operate the other lever or pedal.
When the machine travels over the rear wheels of
trailer, travel the machine slowly so that the smooth
change of machine position (from grading to level) is
possible. pay attention not to make working equipment
hit trailer.
When the machine travels to the middle of the trailer,
slew the upper-structure 180°making the working
equipment face backside of the machine.
