OPERATION & MAINTENANCE MANUAL SWE155F
81
Outdoor Rotary Latch
 Open the cab door: push the door until A
latches with B (see the right fig.1), following a
clack sound, the door is locked( see fig.2).
 Open the cab door：Press the unlock handle on
the right side of under door frame, the fixed
lock will be open,(as fig.3),then close the cab
door.
Emergency exit
 When the cab door cannot open due to some
reasons, “safety hummer” can be used to
broken the back window, you can escape from
the back window.
 Escaping approach：
1. Take the “safety hammer” outward.
2. Break the back window with it, escape from the
outlet.
Remark：
Unless using it as the emergency exit, do not
break the back window.
Fig.1
Fig.2
Fig.3
