LT-A50K5 (’05-MODEL) 9-5
ELECTRICAL
BRAKE + WHEEL
Unit: mm (in)
TIRE PRESSURE
VEHICLE LOAD CAPACITY: 38 kg (841 lbs)
ITEM SPECIFICATION NOTE
Spark plug Type NGK: BPR4H
Gap
0.50 – 0.60
(0.020 – 0.024)
Spark performance Over 8 (0.3) at 1 atm.
Ignition coil resistance
Secondary 13 – 20 kΩ
Plug cap –

- Terminal
Generator coil resistance Primary 100 – 160 Ω B/Y – Ground
Ignition coil primary peak voltage
More than 100 V

+: B/Y

-: Ground
ITEM STANDARD LIMIT
Front brake lever play 3 – 7
(0.12 – 0.28)
—
Rear brake lever play 4 – 6
(0.16 – 0.24)
—
Brake drum I.D.
Front —
80.7
(3.18)
Rear —
110.7
(4.36)
Wheel axle runout
Rear —
3.0
(0.12)
Wheel rim size Front &
Rear
7 × 6.0 AT —
Toe-in (with 30 kg load) 1.5 ± 3
(0.06 ± 0.12)
—
Turning radius 2.0 m
(6.6 ft)
—
Camber 0°—
Caster 3°—
Tra i l 1 0
(0.39)
—
Steering angle Inside 33° 40’—
Outside 24°—
Tire size Front AT16 × 8.00-7✩ —
Rear AT16 × 8.00-7✩ —
Tire tread depth
Front —
4.0
(0.16)
Rear —
4.0
(0.16)
COLD INFLATION
TIRE PRESSURE
kPa kgf/cm
2
psi
FRONT 20 0.20 2.9
REAR 20 0.20 2.9
