3-6 ENGINE
ENGINE REMOUNTING
Remount the engine in the reverse order of engine removal.
• Apply a small quantity of THREAD LOCK “1342” to the threasds
of engine mounting nut B and C.
""
""
" 99000-32050: THREAD LOCK “1342”
• Tighten the engine mounting nuts to the specified torque.
# Engine mounting nut A: 31 N
.
m (3.1 kgf
.
m, 22.5 lb-ft)
Engine mounting nut B: 41 N
.
m (4.1 kgf
.
m, 29.5 lb-ft)
Engine mounting nut C: 31 N
.
m (3.1 kgf
.
m, 22.5 lb-ft)
#
ITEM N
.
m kgf
.
m lb-ft
A Engine mounting nut 31 3.1 22.5
B Engine mounting nut 41 4.1 29.5
C Engine mounting nut 31 3.1 22.5
