ENGINE 3-7
• Install the drive chain.
$
The drive chain joint clip should attached in the way that
the slit end will face opposite the direction of travel.
• Pour the specified amount of transmission oil in to the crank-
case. (!2-8)
% Oil change: 500 ml (0.53/0.44 US/Imp qt)
Overhaul : 550 ml (0.58/0.48 US/Imp qt)
• After remounting the engine, the following adjustments are nec-
essary.
* Engine idle speed .................................................. !2-7
* Throttle cable play.................................................. !2-7
* Rear brake cable play ............................................ !2-10
* Drive chain slack .................................................... !2-8
* Oil pump air bleeding ............................................. !4-13
* Recoil starter.......................................................... !2-11
$
Check the wire and cable routing.
Direction of travel
