FUEL AND LUBRICATION SYSTEM 4-5
SPECIFICATIONS
ITEM SPECIFICATION
Carburetor type MIKUNI VM12SC
Bore size 12 mm
I.D. No 43F0
Idle r/min. 1 800 ± 100 r/min.
Float height 24.5 – 25.0 mm (0.96 – 0.98 in)
Main jet (M.J.)
# 55
Jet needle (J.N.) 3E3-4th
Needle jet (N.J.)
E-6
Pilot jet (P.J.)
# 15
Air screw (A.S.) 1# turns out
Throttle cable play 2 – 4 mm (0.08 – 0.16 in)
I.D. NO. LOCATION
The carburetor has I.D. Number A stamped on its body accord-
ing to its specifications.
