2-14 PERIODIC MAINTENANCE
CHASSIS BOLTS AND NUTS
Tighten initially at 1 month and every 3 months thereafter.
Check that all chassis bolts and nuts are tightened to their specified torque. (Refer to page 2-15 for the
locations of the following bolts and nuts on the motorcycle.)
ITEM N
.
m kgf
.
m lb-ft
1 Front hab nut 65 6.5 47.5
2 Wheel nut (front and rear) 28 2.8 20.5
3 Steering shaft holder bolt 23 2.3 16.5
4 Steering shaft lower nut 29 2.9 21.0
5 Handlebar clamp bolt 13 1.3 9.5
6 Footrest bolt 23 2.3 16.5
7 Rear hab nut 75 7.5 55.0
8 Swing arm pivot nut 102 10.2 74.0
9 Tie-rod lock nut 29 2.9 21.0
0 Rear shock absorber 29 2.9 21.0
A Front brake cam lever nut 3.3 0.33 2.43
B Rear brake cam lever nut 7.7 0.77 5.3
C Front suspension arm bolt 50 5.0 36.5
D Front shock absorber bolt
29 2.9 21.0
(lower and upper)
E Rear brake panel nut 28 2.8 20.5
F Tie-rod end nut 29 2.9 21.0
G Knuckle arm nut 50 5.0 36.0
